Repository README

Note

This is the existing repository README, included directly to avoid a second copy. For the current audit of runtime support, see capabilities.

iPHASimulator v2 is a notebook-driven Python toolkit for building, validating, parameterising, simulating, preprocessing, and analysing polyhydroxyalkanoate (PHA) oligomer systems.

The current v2 workflow focuses on reproducible PHA molecular simulation preparation. It starts from chemically defined PHA oligomers, exports structure files, prepares Amber/GAFF2 and GROMACS/OpenMM simulation inputs, supports HPC execution patterns, and provides early analysis and PHA-enzyme docking preparation notebooks.

This software has been developed by King’s College London under the frame of SATISPHACTION project (https://satisphaction.eu/). SATISPHACTION is a 4-year project awarded in 2025 under the highly competitive EIC Pathfinder Challenge call “Nature-inspired alternatives for food packaging and films for agriculture”. It focuses on developing next-generation, fully biodegradable PHA-based materials for food packaging that replace fossil-based plastics and promote circular economy.

Launch the GUI

From the repository root, launch the Streamlit interface with:

python -m streamlit run pha_gui.py

What It Does

iPHASimulator v2 currently provides:

• RDKit-based PHA oligomer generation for curated common PHAs and custom 3-hydroxy acid monomers.

• Validation and visualisation of generated oligomer structures.

• PDB and SDF export for downstream molecular simulation workflows.

• AmberTools/GAFF2 parameterisation for PHA oligomers.

• OpenMM and GROMACS workflow preparation for dry and solvated systems.

• HPC workflow helpers for repeatable simulation execution.

• GROMACS trajectory preprocessing for analysis-ready trajectories.

• Basic polymer trajectory analysis.

• Residue-to-PHA minimum-distance heatmaps and sampled contact occupancies for existing enzyme–PHA trajectories; see the contact workflow.

• PHA-enzyme docking input preparation for manual HADDOCK workflows.

DFT workflows are not documented as a current v2 capability.

Workflow Overview

Numbered boxes correspond to the tutorial notebooks; dashed outlines indicate optional routes or planned extensions. See the notebook catalogue for prerequisites and run order.

Design -> validation -> structure export -> parameterisation -> MD simulation
       -> trajectory preprocessing -> analysis -> PHA-enzyme docking

The repository is organised around guided notebooks. Reusable code lives in src/iphasimulator; notebooks should remain workflow tutorials rather than the home of core package logic.

Naming Convention

iPHASimulator uses one central naming convention for PHA identifiers:

Meaning	Examples
Monomer / residue code	3HB, 3HO, 3HDD
Polymer code	P3HB, P3HO, P3HDD
Single oligomer chain with n repeat units	P3HB_4, P3HO_8, P3HDD_4
Multi-chain system	25_P3HB_3, 10_P3HO_8
Head/main/tail residue database entries	3HB_H, 3HB_M, 3HB_T

Use src/iphasimulator/naming.py to generate and validate names instead of typing names manually in notebooks or scripts.

Current Status

Area	Status	Notes
Polymer generation	Working	Curated PHA names, side-chain based generation, and custom monomers are implemented in src/iphasimulator.
GAFF2/Amber parameterisation	Working	AmberTools workflow writes GAFF2 mol2, frcmod, prmtop, inpcrd, logs, and timing files.
CHARMM/CGenFF parameterisation	Manual website workflow + checks	05B checks CGenFF topology, penalties and stereochemistry; 06B prepares and validates the Solution Builder package. Both use the packaged example by default.
GROMACS/OpenMM MD workflows	Working/in progress	Dry OpenMM and GROMACS preparation are working; solvated workflows and production-style routes are under active development by notebook.
HPC workflow	Working	YAML/SLURM-oriented helpers and notebook guidance are present for staged runs.
Polymer analysis	Working	Basic analysis notebook supports analysis from preprocessed trajectories.
PHA-enzyme docking preparation	Working/in progress	Notebook 11 prepares docking-ready polymer PDB inputs and manual HADDOCK job notes; docking submission is manual.
Enzyme-polymer MD	Planned	Docked complexes are not yet converted into enzyme-polymer MD systems.
ML/database functionality	Planned	Reusable databases and ML-backed workflows are future work.

Installation

iPHASimulator v2 is installed from the GitHub repository: MMLabCodes/iPHAsimulatorV2.

These instructions assume you are using a terminal on Linux, macOS, or Windows with WSL. The terminal is the application where you type commands such as conda activate ... and python ....

1. Install Conda

Install Miniconda or Anaconda first if conda is not already available on your computer. Conda is not normally installed with pip; it is a separate Python and software environment manager. Conda creates an isolated environment, so the packages for iPHASimulator v2 do not interfere with other Python projects.

Recommended options:

• Miniconda: smaller download, recommended if you only want the package manager and will install packages as needed.

• Anaconda: larger download, includes many scientific Python packages by default.

For most users, Miniconda is enough:

1. Open the Miniconda download page: https://docs.conda.io/en/latest/miniconda.html

2. Download the installer for your operating system.

3. Run the installer and accept the default options unless your institution has specific instructions.

4. Close and reopen the terminal after installation.

On Windows, this project is easiest to use through WSL because AmberTools and many MD tools are Linux-oriented. Install Miniconda inside the WSL terminal, not only in the normal Windows command prompt.

After installing Conda, open a new terminal and check that it works:

conda --version

2. Download iPHASimulator v2

The easiest way to download the repository is with git. First check whether git is installed:

git --version

If that command is not found, install Git. If Conda is working, one simple route is:

conda install -c conda-forge git

If Conda asks Proceed ([y]/n)?, type y and press Enter.

Choose a folder where you keep research software, then download the repository from GitHub:

cd ~
git clone https://github.com/MMLabCodes/iPHAsimulatorV2.git
cd iPHAsimulatorV2

If you do not use git, open the GitHub page in a browser, click Code, choose Download ZIP, unzip the folder, and then open a terminal inside the unzipped folder. The folder may be named iPHAsimulatorV2 or iPHAsimulatorV2-main, depending on how it was downloaded

3. Create and Activate the Environment

Create a new conda environment with Python 3.11:

conda create -n iphasimulator_v2 python=3.11
conda activate iphasimulator_v2

If conda asks Proceed ([y]/n)?, type y and press Enter.

When the environment is active, your terminal prompt should usually start with (iphasimulator_v2).

4. Install the Python Package

The Python dependencies are declared in pyproject.toml. You do not need to type every Python package name manually. From the repository root, run:

python -m pip install -e ".[dev,md,gui]"

This command tells pip to read pyproject.toml and install:

• the core iphasimulator package;

• the main Python dependencies such as RDKit, numpy, pandas, scipy, networkx, and pyyaml;

• the dev tools, including pytest and JupyterLab;

• the md tools, including OpenMM, ParmEd, and MDTraj;

• the gui tools, including Streamlit for the graphical interface.

The -e option means “editable install”. This is useful for development because changes made in src/iphasimulator/ are used immediately without reinstalling the package.

5. Check the Python Installation

Run these commands from the same activated environment:

python -c "import iphasimulator; print('iPHASimulator import OK')"
python -c "from rdkit import Chem; import openmm; import parmed; import mdtraj; import streamlit; print('Python dependencies OK')"

6. Start the Graphical Interface

The graphical interface is provided by pha_gui.py and requires Streamlit. Streamlit is installed automatically when you use the python -m pip install -e ".[dev,md,gui]" command above.

Activate the same Conda environment, move to the repository root, and start the interface with:

conda activate iphasimulator_v2
python -m streamlit run pha_gui.py

Use python -m streamlit run pha_gui.py, not python pha_gui.py. Streamlit must start its web server before the interface can work. Your web browser should open automatically, normally at http://localhost:8501. Press Ctrl+C in the terminal when you want to stop the server.

If Python reports No module named 'streamlit', confirm that the correct Conda environment is active and install the GUI dependencies again:

conda activate iphasimulator_v2
python -m pip install -e ".[gui]"

7. Check External Simulation Tools

Some notebooks call external command-line programs. These are not ordinary Python imports, so they may need to be installed separately in the same conda environment:

• AmberTools for GAFF2 parameterisation (antechamber, parmchk2, tleap);

• GROMACS for GROMACS MD workflows (gmx);

• Open Babel for optional structure conversion (obabel).

Check whether they are available:

which antechamber
which tleap
which gmx
which obabel
gmx --version
obabel -V

If any command is missing, install that external tool before running the notebooks that require it. For example, AmberTools, GROMACS, and Open Babel are available from conda-forge:

conda install -c conda-forge ambertools gromacs openbabel

After installing them, check again:

which antechamber
which tleap
which gmx
which obabel
gmx --version
obabel -V

8. Merge Restarted GROMACS Outputs

Long GROMACS simulations may produce several trajectory (.xtc) and energy (.edr) files after restarts. The merge module discovers the initial step7_production files, the optional unnumbered step8_production_2us files, and numbered continuation files such as part0002 and part0003.

The module can be run directly inside the directory containing the XTC and EDR files. First change into that directory and perform a dry run:

cd /path/to/system_directory
python -m iphasimulator.trajectory_gromacs_merge --dry-run

The dry run prints the numerically ordered input files and planned commands but does not run GROMACS. Review that list carefully. To perform both trajectory and energy merging, run:

python -m iphasimulator.trajectory_gromacs_merge

Alternatively, pass the simulation directory while working elsewhere:

python -m iphasimulator.trajectory_gromacs_merge /path/to/system_directory

The trajectory filename records the highest continuation part included. For example, if part0003 is the highest discovered XTC part, the outputs are:

production_combined_003.xtc
production_combined_003.edr

Both output suffixes record the highest part included in their respective merge. The suffix is numeric: part0009 produces _009.xtc or _009.edr, and part0010 produces _010.xtc or _010.edr. An unnumbered step8_production_2us file is treated as continuation 1; a step-7-only output uses _000.

The module runs gmx check on every input and validates the final outputs. It preserves the original files, does not infer times from filenames, and does not use -settime. Existing combined outputs are protected by default.

Optional flags:

--trajectory-only   Merge only XTC files.
--energy-only       Merge only EDR files.
--skip-check        Skip input and output gmx check validation.
--overwrite         Allow replacement of existing combined outputs.
--dry-run           Print the planned commands without running GROMACS.

If continuation XTC files exist but continuation EDR files do not, the module still merges the trajectory and clearly reports that energy merging was skipped.

9. Start the Notebooks

Then start the notebooks from the repository root:

jupyter lab notebooks/

Generated structures, parameter files, simulation inputs, trajectories, and logs are written under examples/output/, which is ignored by Git.

Testing the Installation

For the enzyme–PHA contact workflow, open src/md_simulation_scripts/enzyme_contacts/enzyme_contacts.ipynb or run python src/md_simulation_scripts/enzyme_contacts/run_enzyme_contacts.py src/md_simulation_scripts/enzyme_contacts/GK13_P3HO_4.yaml. This defaults to a labelled preview. Add --full for every configured sampled frame. Install the optional dependencies with python -m pip install -e ".[analysis]" if needed. See configuration, verified inputs and validation before interpreting results.

The main verification suite is in tests/. After installing the package, run the tests from the repository root with pytest:

python -m pytest tests

Individual workflow areas can also be checked by running a specific test file:

python -m pytest tests/test_build_pha.py
python -m pytest tests/test_export.py
python -m pytest tests/test_md_workflow.py
python -m pytest tests/test_gromacs_runner.py
python -m pytest tests/test_trajectory_preprocessing.py

These tests cover the builder, monomer registry, stereochemistry, structure export, GAFF2 workflow helpers, GROMACS conversion/preparation helpers, HPC workflow helpers, and trajectory preprocessing utilities.

Required Dependencies

Dependency	Purpose
RDKit	PHA molecule construction, stereochemistry handling, structure validation, and SDF/PDB export.
AmberTools	GAFF2 parameterisation through antechamber, parmchk2, and tleap.
OpenMM	Python-native MD validation and OpenMM simulation workflows.
GROMACS	GROMACS dry/solvated workflow execution and trajectory preprocessing.
ParmEd	AMBER-to-GROMACS topology conversion.
MDTraj / MDAnalysis	Trajectory handling and analysis support.
pandas	Workflow tables, status summaries, and analysis data frames.
numpy	Numerical calculations.
matplotlib	Notebook plots and basic analysis visualisation.
Streamlit	Browser-based graphical interface provided by pha_gui.py.
Open Babel	Optional structure format conversion support where needed.

The package metadata also includes supporting Python dependencies such as scipy, networkx, and pyyaml.

Repository Structure

notebooks/   Guided v2 workflow notebooks.
src/         Reusable `iphasimulator` Python package code.
examples/    Thin runnable scripts, YAML workflow examples, SLURM templates,
             and generated output under `examples/output/`.
docs/        Developer and design documentation.
tests/       Automated tests for builders, export, MD workflow helpers,
             GROMACS conversion, HPC helpers, and trajectory preprocessing.

Notebook Workflow

Read the execution cells before Run All: 05A currently enables GAFF2 parameterisation, and 10 runs preparation/solvation/minimisation and can submit with sbatch. 06A, 06C and the quick dry check use default-off execution flags. 05B/06B run their packaged input checks by default.

The notebooks are workflow modules, not a 01→12 sequence. Notebooks 01–04 build the PHA; then pick one workflow; 07 explains HPC execution; choose the relevant analysis or docking module.

• PHA alone in water: 05A → 06A

• Enzyme–PHA in water (the method used for the project’s research simulations): 05B → 06B

• Optional enzyme–PHA alternative with OpenMM: 05A → 06C

Outside the main workflows:

• Optional quick check of 05A parameters: 05A → 05A_quick_check_openmm (the GAFF2 files in OpenMM without water; not a physical result)

Both enzyme workflows need a docked enzyme–PHA complex PDB first; prepare the PHA input for docking with 11_enzyme_docking_setup.ipynb. 06B reproduces the project’s research simulations. 06C is a different force-field setup, so results are not directly comparable with 06B. See the full 06B–06C comparison for matched conditions, inputs, output formats and restart requirements.

Notebook	Purpose	Main output
01_build_pha_oligomer.ipynb	Introduce built-in PHA oligomer generation examples.	Example RDKit PHA molecules for tutorial use.
02_design_custom_pha.ipynb	Select or define a PHA target from user-facing design inputs.	A designed polymer target such as P3HB_4.
03_validate_structures.ipynb	Validate generated oligomers and inspect molecular structures.	Validation summaries and visual checks.
04_export_structures.ipynb	Export validated oligomers to structure files.	PDB/SDF files in examples/output/polymer_structures/.
05A_amber_gaff2_parameters.ipynb	Run AmberTools/GAFF2 parameterisation.	prmtop, inpcrd, GAFF2 mol2/frcmod, and logs under examples/output/md_tests/<SYSTEM>/gaff2/.
05A_quick_check_openmm.ipynb	Optional: check that the 05A GAFF2 files load, minimise and run a few steps in OpenMM without water (run flag off by default).	Short OpenMM logs under examples/output/md_tests/<SYSTEM>/openmm/dry_polymer/; not a physical result.
05B_charmm_cgenff_parameters.ipynb	Check the CHARMM-GUI CGenFF files for the PHA: all stereocentres R, parameter quality scores, CGenFF version; runs on the example dataset by default.	✓/✗ checks of the lig/ files used in 06B (lig_g.rtf or lig.rtf, and lig.prm).
06A_gaff2_gromacs_pha_in_water.ipynb	Convert the 05A GAFF2 PHA to GROMACS (ParmEd) and add CHARMM-style TIP3P water with SOD/CLA: the polymer benchmark method.	gromacs/dry_polymer/ and gromacs/solvated_polymer/ with step5_input.gro, topol.top, mdp files and run scripts.
06B_cgenff_gromacs_pha_enzyme_in_water.ipynb	Prepare and check a CHARMM-GUI Solution Builder GROMACS package of an enzyme + polymer complex in water; runs on the example dataset examples/data/charmm_gui_ANC55_P3HB4/ by default.	A GROMACS run folder with step6.x/step7 files and PASS/FAIL checks.
06C_optional_gaff2_openmm_pha_enzyme_in_water.ipynb	Optional: build an enzyme + polymer complex (ff19SB + GAFF2, from the docked complex PDB) in OPC water at 303.15 K, 0.05 M NaCl and rectangular 3.0 nm padding, with 06B’s stage lengths; a different force-field setup from 06B.	Posed polymer mol2, protein PDB, system.prmtop/system.inpcrd and standalone OpenMM scripts, protocol.json, stage states and checkpoints.
07_hpc_execution.ipynb	Prepare and document local/HPC staged execution.	SLURM scripts, restart guidance, and benchmark execution notes.
08_trajectory_preprocessing.ipynb	Reconstruct, center, wrap, and optionally fit GROMACS trajectories.	step7_centered.xtc, optional step7_fitted.xtc, and representative frames.
09_solvated_polymer_analysis.ipynb	Run basic polymer trajectory analysis.	Analysis tables and plots for metrics such as radius of gyration and SASA.
10_polymer_benchmark_batch.ipynb	Launch and track multi-system MD benchmark preparation.	Benchmark outputs under examples/output/benchmark/.
11_enzyme_docking_setup.ipynb	Prepare the PHA input for manual enzyme docking from the benchmark folder examples/output/benchmark/<SYSTEM>/ (polymer only, after a whole-molecule check).	Docking-ready polymer PDBs and manual HADDOCK job records under examples/output/docking_inputs/.
12_enzyme_polymer_analysis.ipynb	Stability diagnostics for one enzyme–polymer GROMACS production run.	Total energy, protein backbone RMSD and polymer RMSD plots.

Minimal P3HB_4 Benchmark Workflow

P3HB_4 is the default small benchmark system for checking the v2 workflow.

1. Install the environment and start Jupyter:

   conda activate iphasimulator_v2
   jupyter lab notebooks/


2. Run notebooks 01 to 04 using the P3HB tetramer target. The expected exported structure names are:

   examples/output/polymer_structures/P3HB_4.sdf
   examples/output/polymer_structures/P3HB_4.pdb


3. Run 05A_amber_gaff2_parameters.ipynb with P3HB_4 as the target. The expected Amber/GAFF2 outputs are written under:

   examples/output/md_tests/P3HB_4/gaff2/


4. Run the relevant MD notebook for the route being tested:

   • 06A_gaff2_gromacs_pha_in_water.ipynb for the PHA in water with GROMACS (the polymer benchmark method).

   • Optional: 05A_quick_check_openmm.ipynb for a fast OpenMM check of the GAFF2 files without water.

5. For production-style GROMACS trajectories, continue with:

   • 07_hpc_execution.ipynb for local/HPC execution guidance.

   • 08_trajectory_preprocessing.ipynb to generate analysis-ready trajectories.

   • 09_solvated_polymer_analysis.ipynb for basic trajectory analysis.

   • 11_enzyme_docking_setup.ipynb only after suitable production structures are available.

Developer Documentation

• Developer guide

• Notebook guide

Roadmap

• Reusable PHA residue database.

• Head/main/tail building blocks for more robust polymer assembly.

• Mixed PHA sequences and sequence-aware validation.

• Enzyme-polymer MD workflows from reviewed docking poses.

• ML potential and database support for future screening workflows.

Citation and Acknowledgements

Citation information will be added before publication or formal release. Until then, please cite the repository URL and acknowledge the iPHASimulator v2 development team and SATISPHACTION project funding (EIC Pathfinder) when using this software in research outputs.

Funded by the European Union. Views and opinions expressed are however those of the author(s) only and do not necessarily reflect those of the European Union, European Innovation Council and SMEs Executive Agency (EISMEA). Neither the European Union nor the granting authority can be held responsible for them
